Product Description
COOLSTER 3125B 125CC FULLY AUTO ATV
The Coolster ATV-3125B showcases our most dynamic colorways to date. Featuring a green or orange coated frame, new body plastics, and striking decals to compliment, the ATV-3125B will hit the trails with flare and style. Coupled with our reliable 125cc fully-automatic engine, the ATV-3125BÂ’s combination of unique aesthetics and performance make this the ultimate mid sized vehicle.
Features
Brake System | Hub/hydraulic disc |
---|---|
Brake Operation | Hand |
Tires Front/Rear | 19 x 7.00 – 8 / 18 x 9.50 – 8 |
Suspension Front/Rear | Double a-arm/Non-Mono shock |
Engine Oil Capacity | 2.4L |
---|---|
Fuel capacity | 90# |
Height To Seat | 730mm |
L*W*H | 1600x1000x1035mm |
Min Ground Clearance | 120mm |
Wheel base | 990mm |
Weight,G.W./N.W. | 132KG /110KG |
Drive System | Chain, Foot |
---|---|
Transmission | Automatic |
Carton Size | 1160 x700 x610mm |
---|---|
Product Color | Black, Green, White |
Other Details
General Information
• 125cc Single Cylinder 4-Stroke
• Start Type: Electric
• Transmission: F-N-R / Fully Auto
• Engine Cooling: Air/Oil Cooled
• Max Torque: 5.9 Ft/lb @ 5500rpm
• Horsepower: 7.64Hp @ 7500rpm
• Ignition System: Stator & CDI
• Battery Size: 12V, 5Ah
• Fuel Capacity: 0.63 Gallons
• Front Brakes: Dual Drum
• Rear Brakes: Hydraulic Disc
• Front Tires: 19x7-8
• Rear Tires: 18x9.5-8
• Front Suspension: Independent Double A-Arm
• Rear Suspension: Independent Single Swing Arm
• Gross Weight (lbs)/(kg): 291/131
• Net Weight (lbs)/(kg): 242/109
• Overall Size (inch)/(mm): 62x39x40/1574x990x1016
• Height to Seat (inch): 28
• Wheelbase (inch): 37.4
• Ground Clearance (inch): 4.7
Product Dimensions
• Length×Width×Height: (Inches) 48x30x26 / (mm) 1219x762x660.4
• Weight : 280
More Pictures
