Product Description
ALL NEW WITH FRONT AND REAR BRAKES, 196cc- OFF ROAD ONLY, NOT STREET LEGAL [NOT CA LEGAL].
TrailMaster Hurricane 200X Mini Bike, Hydraulic Front and Rear Disc Brake
Features
- Powerful 196cc OHV engine
- Hydraulic front and Rear disc brake
- Equipped with Torque Convertor, CVT drive
- Front and rear suspension
- Aggressive large 19X7-8 front and rear tires
- Stylish fenders
- Headlight
Other Details
Technical Specs
Engine Information
- Engine : Single Cylinder, 196cc, 4‐
- Stroke, OHV
- Starting: Recoil Cord
- Spark Plug Type: Torch ‐ F7RTC
- Cooling: Air cooled
- Bore and Stroke: 68 x 54mm
- Compression Ratio: 8.5:1
- Rated Power: 5.1hp
- Rated Torque: 7.3lbsf.ft@ 2500rpm
- Idle Speed: 1440 +/‐ 150 rpm
- Top Speed: 24mph (39km/h)
- Fuel type: Unleaded 87 octane
- Oil Capacity: .53qt. (.5L)
- Oil Type: SAE 10W‐40
General Information
- Lights: Front Headlight Continuously on
- Drive Type: Chain Drive
- Gear Ratio: Centrifugal clutch
- Shock Type Front: Fork shocks
- Shock Type Rear: Hydraulic
- Tire Type: Low pressure tires
- Rear Brakes: Drum
- Front Tire Size: AT19x7‐8
- Rear Tire Size: AT19x7‐8
Dimension Information
- Length: (Inches)66.14 / (1680mm)
- Height: (Inches)38.58 / (980mm)
- Width: (Inches)31.5 / (800mm)
- Wheelbase: (Inches)45.28 / (1150mm)
- Vehicle Wt.: 167.5lbs / (76kg)
- Weight Cap.: 200lbs / (91kg)
- Ground Clearance: (Inches)6.7 / (170mm)
- Gas Tank Capacity: 0.95gal.(4.2L)
Product Dimensions
- Lengthx Widthx Height: (mm)1500x800x520 / (Inches)60x17x31.5
- Weight : (Lbs)220 / (Kg)100
