Product Description
TAOTAO E1-500 Electric ATV, 500 Watt , Brushless Electric Motor
We offer FREE and fast shipping, a one year engine warranty, low price guarantee, and bulk discounts on all of our products! If you need additional information, donÂ’t be afraid to give us a call at 1-877-214-4563. Also, if you are in the Arlington, TX area, stop by our store to check out these ATVs in person.
Other Details
Technical Specs
E1-500 | |
Motor: | |
Power: | 500 Watt , Brushless Electric Motor |
Rated RPM: | 2800r/min |
Transmission: | Chain Drive |
Rated Torque: | 8 N.m |
Reverse: | Yes |
Adjustable Max Speeds: | 10mph, 15mph, 18mph (Approx) |
Battery: | 36V / 12AH, Sealed Lead Acid Battery |
Charging Time: | 8 Hours |
Chassis: | |
Brake: | Hydraulic Disc |
Front Tire: | 4.10 - 6 |
Rear Tire: | 13 x 5.0 - 6 |
Ground Clearance: | 3.1 Inches (80 mm) |
Seat Height: | 20 Inches (500 mm) |
Wheelbase: | 27.50 Inches (700 mm) |
Max Speed: | 18 mph (30 km/h) |
Load Capacity: | 110 LBS (50 Kgs) |
Frame: | High-Tensile Steel |
Dimension: | |
G.W.(lbs): | 134 LBS (61 Kgs) |
N.W.(lbs): | 112 LBS (51 Kgs) |
Overall Size: | 41 x 26 x 27 Inches (1050 x 670 x 680 mm) |
Carton Size(inch): | 39 x 23 x 17 Inches (990 x 580 x 435 mm) |
