Product Description
The TrailMaster Challenger 300X IRS UTV Extended Cab! It climbs hills. It crosses streams. It conquers sand dunes. The 300X IRS UTV side-by-sides are engineered to corner, cross, accelerate, climb, and take you any place you want to go.
Our fully loaded Challenger 300X UTV has more major improvements!
The long waited TrailMaster Challenger 300X IRS is finally here! Much more Power than the Challenger 150. Suitable for rough terrain. High quality. Graphics Package Included.
Details View
Features
- Powerful water-Cooled 300cc CVT fully automatic with reverse engine
- Aluminum wheels
- 4-wheel independent suspension
- Windshield
- Front steel bumper
- Top LED light bar
- Side rearview mirrors
- Exciting graphics
- Large tires with 22X7-10 in the front and 22X10-10 in the back
- Speedometer and odometer
- Bikini sunshade top
- Side nets
- Turn signals
- Horn
- Trailer Hitch
- 12V outlet
- Top speed 45M/H
- Adjustable steering wheel
- Age group: 16 & older
- Large driving cabin fits person up to 6Â’2
- Electric start with kill switch
- Four-point safety seatbelt
- Individual sporting seats
- Adjustable driver seat: pedal to seat back adjustable from 38” to 43”
- Adjustable heavy duty front and rear shock absorber
- Rack and pinion steering wheel
- Front and rear hydraulic disc brake
- Parking brake
- Large rear utility rack
- Optional winch
Other Details
Technical Specs
Parts breakdown set up manuel
Challenger 300XÂ UTV | Parts | Â |
- EPA certificated and CARB approved
- Engine type: 4-stroke, single cylinder, water- cooled
- Displacement: 276cc
- Max HP: 17.4hp/6500rpm
- Max torque: 16 lb ft/5000rpm
- Bore x stroke: 2.85x2.63 inches
- Max speed: 45 mph
- Ignition: C.D.I
- Starting system: Electric
- Battery: 12V 10Ah
- Engine oil: SAE 15W-40
- Clutch: Automatic CVT with reverse
- Driveline / Driving wheel: Chain / Dual wheel drive
- Suspension F / R: Independent Dual A-arm / Independent Swing-arm
- Brakes, F / R: Both hydraulic brakes, Disc
- Tires, F / R: 22x7-10 / 22x10-10
- Fuel capacity: 1.75 gal
- Weight, G.W. / N.W.: 705 / 617 lbs
- Max load: 500 lbs
- Wheelbase: 72 inches
- OA L x W x H: 98x50x60 inches
- Height to seat: 21 inches
- Min ground clearance: 6.3 inches
