Product Description

At Affordable Atv, we specialize in everything motorized that goes off-road. We’re a licensed dealer with years of experience and thousands of sales under our belts. If you have questions or would like to know more about the TrailMaster 200E XRS EFI Go Kart, give us a call at 1-844-785-7713 and we’ll be happy to help.
Key features:
Fuel injection system operates under any weather and at any altitude
Fully automatic with reverse, high performance 168.9cc GY6 engine with internal F-N-R
Top Speed over 40 M/H
Five-point safety seatbelt
Electric start with kill switch
Fully automatic with reverse, high performance GY6 engine with internal reverse set up
Adjustable steering wheel
Large tires with 20X7-8 in the front and 21X10-10 in the back, steel wheel
LED head light
Bikini sunshade top
Adjustable driver seat: pedal to seat back adjustable from 36” to 43”
Adjustable heavy duty front and rear shock absorber
Rack and pinion steering wheel
Front and rear hydraulic disc brake
4-point rear swing arm
Parking brake
4-wheel fenders
Trailer hitch
Large rear utility rack
Large gas tank
Shipping and Fuel surcharge Notice (If choosing Home delivery or business delivery):
About 99% of the customers will not get any shipping / Fuel surcharges, however only about 1% of the customers might get the surcharges on a case by case basis. Shipping to a very far away states and some rural area will incur extra shipping charges like NY, WA, SD, ND, MI, WA, CA, MT, OR, NV, ME, MA,PA, CT, DC, NH, NE and the East Coast etc will be extra due to excessive fuel surcharges, and shipping to any islands will be extra. Please place your order normally if there are any extra shipping charges we will call you to inform you if not we will process your order as normal. We do not ship it to Hawaii and Alaska. Thank you for your understanding.
Other Details
Technical Specs
Parts breakdown set up manuel
| 200XRSE & 200XRXE | Parts | Â |
Model: 200E XRS
Engine Information
EPA certificated
Engine type: 4-stroke, single cylinder, air cooled
Displacement: 168.9cc
Max HP: 11.1hp/8000rpm
Max torque: 8.1 lb ft/6000rpm
Bore x stroke: 2.4x2.28 inches
Max speed: 43 mph
Climbing ability: 18 degrees
Ignition: ECU
Starting system: Electric
Battery: 12V 10Ah
Engine oil: SAE 15W-40
General Information
Clutch: Automatic CTV with reverse
Driveline / Driving wheel: Chain / Dual wheel drive
Suspension F / R: Double A-arm / swing-arm
Brakes, F / R: Both hydraulic brakes, Disc
Tires, F / R: 20x7-8 / 21x10-10
Wheel: Steel
Fuel capacity: 2.25 gal
Weight, G.W. / N.W.: 750 / 485 lbs
Max load: 500 lbs
Dimension Information
Wheelbase: 59 inches
OA L x W x H: 91.5*47.5*26.5 inches
Crate size: 91.5*47.5*26.5 inches
Shipping weight: 750lbs
Height to seat: 13.8 inches
Min ground clearance: 6.7 inches
Pedal to seat back distance: 36” to 43”
