Product Description
RPS DB-Viper 150CC Dirt Bike, 4 Stroke Displacement, Air Cooling - Fully Assembled And Tested
When you're investing in motorsports, make sure you get your moneyÂ’s worth by working with the best in the business. Affordable Atv offers unbeatable prices on the RPS DB-Viper 150CC Dirt Bike, and itÂ’s backed by a 1-year warranty. WeÂ’ll even ship your order right to your door FREE of charge.
Affordable Atv is proud to announce our new FULLY ASSEMBLED - READY TO RIDE OPTION! Let the pro's assemble your new ATV, it will arrive to your door built right, run tested and ready to ride. The only thing you do is 1. Hook up the battery, 2. Put gas in it and go riding!
Ready to Ride Option Includes The Following:
1. Check Starter Switch
2. Check Kill Switch
3. Check all lights including Head Lights, Low & High Beams, Rear Tail Lights and Brake Lights
4. Check Rear Safety Wrist Strap Kill Switch* *Not on all Models
5. Mount Tires & Wheels and Check Tire Pressure
6. Check (Engine Oil, Transmission Oil, Brake System Fluid,)
7. Adjust Carburetor for proper idle and run speed
8. Check Transmission, Chain Drive, Brakes and Electrical Connections
9. Check Battery and Check the Charging System
10. Check all Remote Control Features including Engine Kill and Alarm
11. Once completed we Custom Package and Ship your ATV Ready to Ride!
Other Details
Technical Specs
Technical Specs
ENGINE INFO: DB-Viper 150cc
Engine Type: 149cc 4 stroke Displacement, air cooling
Compression Ratio: 9.0:1
Ignition Type: CDI
Bore and Stroke: 69x53
Number of Cylinder: 1
Transmission: Manual (5 Gears)
Starter mode: Kick start
Max Power: 9.5 KW / 8500 rpm
Max Torque: 10.0 N.M / 6500 rpm
CHASSIS/SUSPENSION/BRAKES
Front Suspension: Double Shocks
Rear Suspension: Single Shock
Braking system: Front and Rear Hydraulic disc
Dimensions
Length (mm): 1930
Width (mm): 1000
Height(mm): 1199
Wheel Base:
Dry Weight (kg): 100
Seat Height (mm): 820
Wheelbase (mm): 1320
Weight Capacity (kg): 120
Ground Clearance (mm): 230
Front and Rear Wheel:
70/9100-19" 90/100-16"
Tank Capacity:5.7
Engine Oil Capacity (L): 1.0
Catron Dimensions
Lenght(mm) 1630
Width(mm) 450
Height(mm) 770
Packing Weight(kg) 115
Available Color:
Red/Green/Blue/Black
