Product Description
Trailmaster R125 Atv, 125Cc 4-Stroke, Air Cooled, Single Cylinder
The Trailmaster R125 ATV is designed for adventure seekers, featuring a robust 125cc engine that combines power and ease of use. Its automatic transmission with reverse capability allows for effortless maneuvering, making it ideal for both beginners and experienced riders. With a maximum load capacity of 143 lbs, this ATV is perfect for carrying gear or accommodating a passenger, ensuring you can make the most of your outdoor excursions. It operates on SAE 15W/40 engine oil, which provides excellent lubrication and protection for long-lasting performance.
With a top speed of 29 miles per hour, the Trailmaster R125 delivers an exhilarating ride without compromising safety. Its chain final drive system ensures a smooth transfer of power to the wheels, enhancing traction and stability on various terrains. Whether you're navigating rugged trails or enjoying leisurely rides, this ATV offers reliability and versatility, making it an excellent choice for young riders and families looking for a thrilling yet manageable off-road experience.
Other Details
TECHNICAL SPECS
SPECIFICATIONS
ENGINE INFO
Engine type: 125cc 4-stroke, air cooled, single cylinder
Displacement: 120cc
Max horsepower: 5.3kW/8000/min
Bore*stroke: 52.4 x 55.5 mm
Max speed: 29 m/h
Ignition: CDI
Starting system: Electric start
Engine Oil: SAE 15W/40
Battery: 12V, 5Ah
CHASSIS
Transmission: Auto with Reverse
Final Drive: chain
Driving wheel: Rear wheel drive
Front Suspension: Double a-arm
Rear Suspension: Solid axle
Brakes: Front brake: drum brake / Rear brake: disc brake
Tires: front/rear: 16 x 8- 7 / 16 x 8- 7
Fuel capacity: 2.06 L
Net Weight: 160.5 lbs.
Gross Weight: 226.2 lbs.
Max load: 143 lbs.
DIMENSIONS
Wheelbase: 33.46”
Overall size (L*W*H): 53”X31”X35”
Height to seat: 23.62”
Min ground clearance: 3.35”
Packing size: 54”X32”X30”
