Product Description
Other Details
Technical Specs
Model | Challenger 200X UTV |
EPA Off-Road Approved | Yes |
Engine Type | 4-stroke, single cylinder, air cooled |
Displacement | 168.9cc |
Max HP | 11.1 hp/7500rpm |
Max torque | 8 lb ft/6000rpm |
Bore x stroke | 2.26x2.28 inches |
Max speed | 35 mph |
Climbing ability | 20-25 degrees |
Ignition | C.D.I |
Starting system | Electric |
Battery | 12V 10Ah |
Engine oil | SAE 15W-40 |
Clutch | Automatic CTV with reverse |
Driveline / Chain | Driven / Dual wheel drive |
Suspension F / R | Independent Dual A-arm / Double Oil Damped Shock |
Brakes, F / R | Both hydraulic brakes, Disc |
Tires, F / R | 22x7-10 / 22x10-10 |
Fuel capacity | 1.75 gal |
Weight, G.W. / N.W. | 750 / 528 lbs |
Max load | 500 lbs |
Dimension Information | |
Wheelbase | 72 inches |
OA L x W x H | 90.16*51.97*33.5 inches |
Height to seat | 21 inches |
MinGround clearance | 6.3 inches |
More Pictures
