Product Description
When you’re investing in motorsports, make sure you get your money’s worth by working with the best in the business. AffordableAtv offers unbeatable prices on the RPS HX250 DLX 250cc Dirt Bike, and it’s backed by a 1-year warranty. We’ll even ship your order right to your door FREE of charge.
Other Details
Technical Specs
ENGINE
ENGINE TYPE: CB250cc A/C
DISPLACEMENT: 232.6 ml
DESIGN TYPE: 1-Cylinder, 4-Stroke, camshaft upwards, tilting
BORE & STROKE: 69mm X 69.2mm
STARTER: Electrical & Kick Start
TRANSMISSION: 5-Speed
PRIMARY DRIVE: 3.33
SECOND GEAR RATIO: 1.867
CARBURETOR: KF PZ30
SPARK PLUG: NGK
BATTERY: 12V 7Ah Lead Acid Battery
SUSPENSION
FRONT: FORK XMotos T6 Series Inverted Forks, Non-Adj
TRIPLE CLAMP & RISERSForged Alloy Triple Clamp & Risers
REAR: SHOCK XMotos T6 rear shock absorber. Non-Adj
SUPENSION LINKAGE With Suspension Linkage
WHEELS
RIM Steel Rim
TIRE Weixing Off Road Knobby Tire (21/18)
RIM LOCK Optional Front & Rear Rim Lock
CHAIN KMC 520
MAJOR BODY PARTS
FRAME & SUB FRAME: Tube Cradle Frame, High Strength Steel (made in house )
REAR SWING ARM High Strength Steel ( made in house )
AXLE, BOLT & NUTS 10.9 grade axles, army green coating for most of bolt & nuts for important parts
DIMENSION AND WEIGHT
WHEEL BASE: 1360 mm
Overall Length: 2025 mm
Overall Width: 830 mm
Overall Height: 1150 mm
Seat Height: 885 mm
Ground Clearance: 300 mm
Dry Weight: 101.5 Kgs
Max. Load: 115.5 kgs
Fuel Tank Capacity: 7.5L
Packing Size: 177x42x81 cm
