Product Description
TaoTao DB20 107CC, Air cooled, 4-Stroke, Single-Cylinder, Automatic
At Affordable Atv, we specialize in everything motorized that goes off-road. WeÂ’re a licensed dealer with years of experience and thousands of sales under our belts.
If you have questions or would like to know more about the TaoTao DB20 107CC, Air cooled, 4-Stroke, Single-Cylinder, Automatic, give us a call at1-844-785-7713 and weÂ’ll be happy to help.
Other Details
Technical Specs
| DB20 | |
| ENGINE: | |
| Engine Type: | 107cc,Air cooled, 4-stroke, single-cylinder, Automatic |
| Start Type: | Electric Start |
| Transmission: | Chain Drive |
| Engine Gear: | Automatic |
| Wheelbase(inch): | 38 Inches (965mm) |
| Ignition: | CDI |
| Fuel Capacity: | 0.8 Gal (3 L) |
| Battery: | 12V 5Ah (Included) |
| CHASSIS: | |
| Front Brake: | Hydraulic Disc --- Hand Braker |
| Rear Brake: | Hydraulic Disc ---Hand Braker |
| Tire Front: | 2.75 - 10 |
| Tire Rear: | 2.75 - 10 |
| Rim Front: | 1.4 x 10 |
| Rim Rear: | 1.4 x 10 |
| Max Speed: | 30 MPH (50 KM/H) |
| DIMENSION: | |
| G.W.(lbs): | 136 LBS (62KG) |
| N.W.(lbs): | 116 LBS (52.5KG) |
| Overall Size(inch): | 53 x 25 x 33 Inches (1380 x 630 x 850 mm) |
| Carton Size(inch): | 48 x 15 x 24 Inches (1210 x 380 x 600 mm) |
| Seat Height: | 24 Inches (615 mm) |
| Ground Clearance: | 7.3 Inches (185 mm) |
